Crude Oil Refining (Animal & Vegetable Oil 1-10T)

Olive Pomace Oil Refinery Plant | 10–500 TPD

Capacity: 10–500 TPD Suitable Plant Types: Batch Refinery Plant, Semi-Continuous Refinery Plant, and Continuous Refinery Plant. Applicable Raw Materials: Crude olive pomace oil, olive residue oil, olive cake oil, and high-FFA olive pomace oil. Final Product Applications: Edible oil, cosmetic oil, biodiesel, soap manufacturing, and oleochemical products.

Send Email

Chat Now

Share With:

Product Description Refining Process & Equipment Features Related Products

Product Description

Dingsheng Machine professionally provides olive pomace oil refining plants designed to process crude olive pomace oil into high-quality refined edible oil. The complete system integrates degumming, neutralization, bleaching, deodorization, dewaxing, and filtration processes to effectively improve the oil’s color, clarity, stability, and shelf life.

The production line features a high level of automation, stable operation, low energy consumption, and strong adaptability, making it suitable for olive pomace oil refining projects of different capacities.

Refining Process & Equipment

Refining Process :
Degumming:
Hydration degumming or acid degumming technology is used to remove phospholipids, gums, and suspended impurities.

Neutralization:
Alkali refining is adopted to remove free fatty acids. Physical refining processes can also be selected according to the quality of the crude oil.

Water Washing & Drying:
Removes residual soapstock and moisture to improve the stability of subsequent refining processes.

Bleaching:
Activated bleaching earth is used to adsorb pigments, peroxides, and trace metals, improving the color and quality of the oil.

Dewaxing / Winterization:
A key process in olive pomace oil refining. Through low-temperature crystallization, slow agitation, and filtration systems, waxes are effectively removed to enhance low-temperature clarity and oil stability.

Deodorization:
Under high vacuum and steam stripping conditions, odors, volatile substances, and residual free fatty acids are removed.

Fine Filtration:
Final filtration ensures the production of clear, stable, and higher-quality refined olive pomace oil.

Main Equipment:
Neutralization Tank
Bleaching Tank
Deodorization Tower
Dewaxing Tank
Crystallization System
Fine Filter
Vacuum System
Steam Generator
PLC Automatic Control Cabinet

Features

High-Quality Refined Oil: The refined olive pomace oil features a lighter color, lower acid value, higher transparency, milder odor, longer shelf life, and greater market value.

Professional Dewaxing System: Equipped with a low-temperature crystallization and fine filtration system to effectively remove waxes and improve oil clarity and stability under low-temperature conditions.

Suitable for High-FFA Crude Oil: The system is specially designed for high free fatty acid olive pomace oil, offering stronger refining adaptability and more stable processing performance.

Energy-Saving Design: Optimized heating and heat recovery systems help reduce steam and electricity consumption, lowering overall operating costs.

PLC Fully Automatic Intelligent Control: The PLC touch-screen control system supports automatic monitoring and parameter adjustment, ensuring continuous and stable operation while reducing manual labor.

Food-Grade Stainless Steel Material: All parts in contact with oil are made of 304/316L food-grade stainless steel, offering excellent corrosion resistance, easy cleaning, and long service life.

Stable Continuous Production: The equipment operates reliably and is suitable for long-term continuous refining production with low failure rates and convenient maintenance.

Environmentally Friendly & Safe Operation: Equipped with a vacuum deodorization and exhaust gas treatment system to reduce emissions, improve production safety, and meet modern environmental standards.

Edible Oil Processing With Dingsheng Machine

Dingsheng Machine is a leading manufacturer specializing in edible oil processing solutions and equipment in China, we provide complete plant solutions for oilseeds pretreatment, solvent extraction, refining and deep processing. More than 20 years’ experience, we are committed to optimizing technology processes, engineer design, project management, installation and training, help customer build the oil mill over the world. When you plan to build an vegetable oil processing plant, please contact us today to get the quote.
Email: company@dingmachinery.com, whatsapp: +86-159 3716 3029.
